BOD | SMR 46 (BOD 센서)
페이지 정보
작성자 최고관리자 작성일21-02-04 14:23 조회109회 댓글0건본문
-
- IP68 방진 방수구조
- 플러그 앤 플레이
- 자동 클리닝 와이퍼
- 소프트웨어를 통한 교정
- 사파이어 재질로 내구성 업
◈ Description
Biochemical Oxygen Demand Analyzer is connected directly via RS485 communication interface, providing simple, reliable, cost- saving process data with remote monitoring, calibration, configuration and diagnostics capabilities.
The Biochemical Oxygen Demand Meter housing in a robust IP68 proof enclosure, 1500 N tensile strength Kevlar reinforced cable,, up to 1.2 km digital data transmission,BOD Analyzer and BOD meter is ideally used in water/wastewater industry
◈ Features
- All-in-One Compact Housing, Built-in Transmitter and Sensors
- Robust IP68 Water Submersible Protection
- Plug & Play, On-line Realtime Measurement
- Ultra Low Power Consumption, Ideal for Outdoor Applications
- 1500 N Tensile Strength Kevlar Reinforced Cable
- Surge Protection for Power and RS485 Communication
- RS485 Digital Communication, Minimize Cabling and Engineering Cost
- Standard Modbus RTU Protocol, Direct Connected with PLC, HMI
- Sapphire Glass Windows to Prevent Scratch
- Innovative Nano Coating to Remain Window Clean
- Auto Cleaning Wiper, Less Maintenance
- Turbidity or Suspended Solids Compensation
- Onboard Memory Allowing Users Easily Calibrate and Configure Sensor at Lab and Distribute to Various Fields Sites
- Software Tool for Data Monitoring, Calibration , Configuration and Diagnosis
Typical Application
Drinking water, surface water, industry, water treatment, wastewater
General
- Output Signal:RS485 (Modbus RTU protocol), 19,200 bps, 8 data bits, no parity, 1 stop bit; 4~20 mA (optional)
- Data Resolution: 16 bits (0.001% FS)
- Surge Protection: 4000 V DC
- Power: 3.6~12 V DC ±10%, 20mA
- Protection: polarity, overload, short circuit
- Safety: CE, FCC
- Drinking water, surface water, industry, water treatment, wastewater
- The analyzer consists of a light source, a sample cell, and a light detector (photo detector). Incident light is absorbed by the sample, and the light is measured by the detector. The value depends on the amount of absorbance in the sample. The transmitter uses a long life LED and the 180° light method in accordance with International standard to assure accurate measurement values. An automated mechanical wiper is to remain surface clean and remove air bubbles of the optical window in order to maximize the accuracy and minimize the maintenance requirement.
