| 사양설명: |
|
|
|
측정범위 (pH) |
|
0.00 to 14.00 pH |
|
최소측정단위 (pH) |
|
0.01 pH |
|
정확도 (pH) |
|
±0.02 pH |
|
측정범위 (mV of pH
input) |
|
±600.0 mV |
|
최소측정단위 (mV of pH
input) |
|
0.1 mV |
|
정확도 (mV of pH
input) |
|
±0.5 mV |
|
측정범위 (ORP) |
|
±2000.0 mV |
|
최소측정단위 (ORP) |
|
0.1 mV |
|
정확도 (ORP) |
|
±1.0 mV |
|
측정범위 (Dissolved
Oxygen) |
|
0.0 to 500.0% / 0.00 to 50.00
mg/L |
|
최소측정단위 (Dissolved
Oxygen) |
|
0.1% / 0.01 mg/L |
|
정확도 (Dissolved
Oxygen) |
|
0.0 to 300.0%: ±1.5% of reading or ±1.0%
whichever is greater; 300.0 to 500.0%: ±3% of reading; 0.00 to 30.00 mg/L: ±1.5%
of reading or 0.10 mg/L whichever is greater; 30.00 mg/L to 50.00 mg/L: ±3% of
reading |
|
측정범위
(Conductivity) |
|
0.000 to 200.000 mS/cm (actual EC up to 400
mS/cm) |
|
최소측정단위
(Conductivity) |
|
Manual: 1 μS/cm; 0.001 mS/cm; 0.01 mS/cm; 0.1
mS/cm; 1 mS/cm Automatic: 1 μS/cm from 0 to 9999 μS/cm; 0.01 mS/cm from 10.00 to
99.99 mS/cm ; 0.1 mS/cm from 100.0 to 400.0 mS/cm Automatic mS/cm: 0.001 mS/cm
from 0.000 to 9.999 mS/cm; 0.01 mS/cm from 10.00 to 99.99 mS/cm; 0.1 mS/cm from
100.0 to 400.0 mS/cm |
|
정확도
(Conductivity) |
|
±1% of reading or ±1μS/cm whichever is
greater |
|
Range
(Resistivity) |
|
0 to 999999 Ohm/cm; 0 to 1000.0 kOhm/cm; 0 to
1.0000 MOhm/cm |
|
최소측정단위
(Resistivity) |
|
Dependent on resistivity
reading |
|
측정범위 (TDS) |
|
0 to 400000 mg/L or ppm (the maximum value
depends on the TDS factor) |
|
최소측정단위 (TDS) |
|
Manual: 1 mg/L (ppm); 0.001 g/L (ppt); 0.01g/L
(ppt); 0.1 g/L (ppt); 1 g/L (ppt) Auto-range scales: 1 mg/L (ppm) from 0 to 9999
mg/L (ppm); 0.01 g/L (ppt) from 10.00 to 99.99 g/L (ppt); 0.1 g/L (ppt) from
100.0 to 400.0 g/L (ppt) Auto-range g/L (ppt) scales: 0.001 g/L (ppt) from 0.000
to 9.999 g/L (ppt); 0.01 g/L (ppt) from 10.00 to 99.99 g/L (ppt); 0.1 g/L (ppt)
from 100.0 to 400.0 g/L (ppt) |
|
정확도 (TDS) |
|
±1% of reading or ±1mg/L |
|
측정범위
(Salinity) |
|
0.00 to 70.00 PSU (extended Practical Salinity
Scale) |
|
최소측정단위
(Salinity) |
|
0.01 PSU |
|
정확도 (Salinity) |
|
±2% of reading or 0.01 PSU whichever is
greater |
|
측정범위 (Seawater Specific
Gravity) |
|
0.0 to 50.0 st, s0, s15 |
|
최소측정단위 (Seawater Specific
Gravity) |
|
0.1 st, s0, s15 |
|
Accuracy (Seawater Specific
Gravity) |
|
±1 st, s0, s15 |
|
측정범위 (Atm.
Pressure) |
|
450 to 850 mmHg; 17.72 to 33.46 inHg; 600.0 to
1133.2 mbar; 8.702 to 16.436 psi; 0.5921 to 1.1184 atm; 60.00 to 113.32
kPa |
|
최소측정단위 (Atm.
Pressure) |
|
0.1 mmHg; 0.01 inHg; 0.1 mbar; 0.001 psi;
0.0001 atm; 0.01 kPa |
|
정확도 (Atm.
Pressure) |
|
±2 mmHg within 15℃ from the temperature during
calibration |
|
Range (Temp) |
|
-5.00 to 55.00℃; 23.00 to 131.00℉; 268.15 to
328.15K |
|
최소측정단위 (Temp) |
|
0.01℃; 0.01℉; 0.01K |
|
정확도 (Temp) |
|
±0.15℃; ±0.27℉; ±0.15K |
|
측정범위(Nitrate) |
|
0.02 to 200.0 ppm |
|
최소측정단위(Nitrate) |
|
0.01 ppm to 1 ppm; 0.1ppm to
200ppm |
|
정확도 (Nitrate) |
|
±5% of reading or 2 ppm |
|
측정범위(Turbidity) |
|
0.0 to 50.0 FNU; 50 to 1000
FNU |
|
최소측정단위(Turbidity) |
|
0.1 FNU from 0.0 to 50.0 FNU; 1 FNU from 50 to
1000 FNU |
|
정확도(Turbidity) |
|
±0.3FNU or ±2% of reading, whichever is
greater |
|
보정 (pH) |
|
Automatic 1, 2, or 3 points with 5 memorized
standard buffers (pH 4.01, 6.86, 7.01, 9.18, 10.01) or 1 custom
buffer |
|
보정 (ORP) |
|
Automatic at 1 custom point |
|
보정 |
|
Automatic 1 point with 6 memorized standards
(84 μS/cm, 1413 μS/cm, 5.00 mS/cm, 12.88 mS/cm, 80.0 mS/cm, 111.8 mS/cm) or
custom point |
|
보정 |
|
Automatic 1 or 2 points at 0, 100% or 1 custom
point |
|
보정 |
|
Based on conductivity or salinity
calibration |
|
보정 |
|
Automatic at 1 custom point |
|
보정 |
|
Automatic at 1 custom point |
|
보정 |
|
1 or 2 point 10 ppm and 100 ppm memorized
standards |
|
보정 |
|
Up to 3 points |
|
온도보정 |
|
Automatic from -5 to 55℃ |
|
Logging 메모리 |
|
Up to 46000 samples with 18 measurements
each |
|
Logging 간격 |
|
1 second to 3 hours |
|
Computer
Interface |
|
USB (with HI 929829 software) |
|
방수보호 |
|
Meter IP67, Probe IP68 |
|
환경 |
|
0 to 50℃; RH 100% |
|
Power Supply |
|
(4) 1.5V alkaline C cells (대략. 배경조명 없이 150
시간)/ (4) 1.2V rechargeable C cells (배경조명 없이 약. 70 시간) |
|
규격 |
|
Meter: 221 x 115 x 55 mm; Probe: 270 x 46 mm
DIA |
|
무게 |
|
Meter: 750g (26.5 oz.); Probe: 750g (26.5
oz.) |
