CO | SMR 51 (CO 센서)
페이지 정보
작성자 최고관리자 작성일21-02-04 15:32 조회116회 댓글0건본문
-
- IP68 방진 방수구조
- 플러그 앤 플레이
- Modbus RTU 제공
- 소프트웨어를 통한 교정
- 강력한 인장 내구성
◈ Description
The Carbon Monoxide Gas Analyzer is connected directly via RS485 communication interface, providing simple, reliable, cost-saving process data with remote monitoring, calibration, configuration and diagnostics capabilities.
CO Gas Analyzer in a robust IP68 proof enclosure, 1500 N tensile strength Kelvar reinforced cable, up to 1.2 km digital data transmission, the transmitter is ideally used in gas utilities, industrial manufacturing, water and waste water facilities.
◈ Features
- All-in-One Compact Housing, Built-in Transmitter and Sensors
- Robust IP68 Water Submersible Protection
- Plug & Play, On-line Realtime Measurement
- Ultra Low Power Consumption, Ideal for Outdoor Applications
- 1500 N Tensile Strength Kevlar Reinforced Cable
- Surge Protection for Power and RS485 Communication
- RS485 Digital Communication, Minimize Cabling and Engineering Cost
- Standard Modbus RTU Protocol, Direct Connected with PLC, HMI
- Onboard Memory Allowing Users Easily Calibrate and Configure Sensor at Lab and Distribute to Various Fields Sites
- Software Tool for Data Monitoring, Calibration , Configuration and Diagnosis
Typical Application
Industry, water treatment, wastewater, gas, petrochemical
General
- Output Signal: RS485 (Modbus RTU protocol), 19,200 bps, 8 data bits, no parity, 1 stop bit; 4~20 mA (optional)
- Data Resolution: 16 bits (0.001% FS)
- Surge Protection: 4000 V DC
- Power: Power: 5 or 12 V DC ±10%, 1 A
- Protection: polarity, overload, short circuit
- Safety: CE, FCC
- Industry, water treatment, wastewater, gas, petrochemical
- Electrochemical sensor operated by reacting with the gas of interest and producing an electrical signal proportional to the gas concentration
